Allied Telesis GS900/5E manual Technical Specifications, Appendix a, Physical Specifications

Page 38

Appendix A

Technical Specifications

Physical Specifications

Dimensions:

(W x D x H)

AT-GS900/16

330 mm x 230.5 mm x 43 mm



(13.0 in x 9.07 in x 1.7 in)

AT-GS900/24

330 mm x 230.5 mm x 43 mm



(13.0 in x 9.07 in x 1.7 in)

Weight:



AT-GS900/16

2.38 kg (5.25 lbs)

AT-GS900/24

2.99 kg (6.60 lbs)

Environmental Specifications







Operating Temperature:

0° C to 40° C (32° F to 104° F)

Storage Temperature:

-25° C to 70° C (-13° F to 158° F)

Operating Humidity:

5% to 90% non-condensing

Storage Humidity:

5% to 95% non-condensing

Operating Altitude Range:

Up to 10,000 feet (3,048 meters)

Power Specifications



Power Consumption:



AT-GS900/16

15.3 watts maximum

AT-GS900/24

20.1 watts maximum

AC Input Electrical Ratings:

100 - 240V AC, 1A

Frequency:

50/60 Hz

38
