Using Your Inspiron Laptop

1 AC adapter connector – Connects to the AC adapter to power the computer and charge the battery.

2 Network connector – Connects to a network or a broadband device if you are using a wired network.

3 HDMI connector – Connects to a TV for both 5.1 audio and video signals. NOTE: When used with a monitor, only the video signal is read.

4 VGA connector – Connects to video devices, such as a monitor or a projector.

5 USB 2.0 connector – Connects to USB devices, such as a mouse, keyboard, printer, external drive, or MP3 player.

19
