Important Safety
Information
Introduction
WARNING Power inverters contain components that tend to produce arcs or sparks. To prevent fire or explosion, do not install the inverter in areas or compartments containing batteries or flammable materials or in locations that require ignition- protected equipment.
WARNING To reduce the risk of fire, do not cover or obstruct the ventilation openings. Do not install inverter in
Warning: Wash Hands After Handling Power Cord
The power cord on this product contains lead, a chemical known in the state of California to cause birth defects or other reproductive harm.
Caution: Rechargeable Appliances
Certain chargers for small nickel cadmium batteries can be damaged if connected to the Cobra® 800W inverter. Two (2) particular types of equipment are prone to this problem:
Quick Evaluation
Before Installation
Introduction
Cobra® 800W Output Waveform
Some very sensitive electronic equipment may not operate satisfactory on “square wave” or “modified sine wave.” The output waveform is referred to as “square wave” or “modified sine wave.” It is a stepped waveform designed to have characteristics similar to the sine wave shape of utility power. A waveform of this nature is suitable for most AC loads (including linear and switching power suppliers used in electronic equipment, transformers and motors).
Quick Evaluation Before Installation
•
This section provides you with basic information about the inverter and how to check its performance before installation.
Be Sure to Have on Hand:
A 12 volt DC power source (such as a vehicle battery).
Power Supply | The power source must provide |
| between 11 and 15 volts DC and |
| be able to supply enough current to |
| run the test load. As a rough guide, |
| divide the wattage of the test load by |
Plug In Directly
Dangerous Voltages
1.Small
2.Certain battery chargers for battery packs used in hand power tools. These chargers have a WARNING label stating that dangerous voltages are present at the battery terminals.
10 to get the current (in amperes) |
the power source must deliver. |
The provided 2 ft.
Cable | Only use the cable provided with |
| your inverter. |
A test load that can be plugged into the AC receptacle on the inverter for short term testing at a low power level.
This problem does not occur with the vast majority of battery operated equipment. Most use a separate charger or transformer that is plugged into the AC receptacle and produces a low voltage output. If the label on the AC adapter or charger states that it produces a low voltage AC or DC output (less than 30 volts), the inverter will have no problem powering the adapter safely.
Test Load
