￿Printer Driver Settings

To view Help for a setting, click the () button in the upper right-hand corner of the window and then click the setting.

Tab

Index which allows you to switch between the various setup screens.

The settings you made at "N-Up Printing", "Fit To Paper Size", "Image Orientation" and "Watermark" are shown in this image.

Check box

Click this option to activate/ deactivate each function.

The tray selected in "Paper Selection" in the

"Paper" tab appears in blue. You can also click on a tray to select it.

"OK" button

Click this button to save your

"Cancel" button





settings, and exit the dialog

Click this button to exit the dialog box

box.

without making any changes to the



settings.

( ) button

Click this button and then click a setting to view Help for the setting.

You can also view Help by right-clicking the setting

Note with the mouse.

Drop-down list

Allows you to make one selection from a list of choices.

"Apply" button

Click to save your settings without closing the dialog box.

Windows NT 4.0 does not

have the "Apply" button Note on each screen.

The "Apply" button does not appear when you open this window from an application.
