Acer C300 Series manual Information, Parameter

Page 45

Information

PhoenixBIOS Setup Utility



Information



Main

Advanced

Security

Boot

Exit





















CPU Type:





Intel (R) Pentium (R) M processor









CPU Speed:





1500 MHz













Floppy Drive:





None















IDE1 Model Name:



None















IDE1 Serial Number:



None















IDE2 Model Number:



QSI CD-RW/DVD-ROM SBW242U- (SM)









IDE2 Serial Number:



None















System BIOS Ver:



Canary V0.20













VGA BIOS Ver:



2991















KBC Ver:



02.13.29













Serial Number:





xxxxxxxxxxxxxxxxxxxxxx











Asset Tag Number:



N/A















Product Name:





TravelMate C300













Manufacturer Name:



Acer















UUID:





xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx













































F1 Help

↑ ↓

Select Item



F5/F6 Change Values



F9 Setup Defaults





Esc Exit

← → Select Menu

Enter

Select 4Sub-Menu

F10 Save and Exit





























Parameter











Description























IDE1 Model Name





Shows the Model name of HDD installed on Primary IDE master. The hard disk model











name is automatically detected by the system. If there is no hard disk present or unknown











type, “None” should be shown on this field.









IDE1 Serial #





This field display the Serial number of HDD installed on Primary IDE master. If no Hard











disk or other devices are installed on Primary IDE master, then it will display a blank line.

















IDE2 Model Name





This item will show the Model name of device installed on Secondary IDE master. The











hard disk or CD-ROM model name is automatically detected by the system. If there is no











hard disk or CD-ROM present or unknown type, “None” should be shown on this field.



IDE2 Serial #





This item will show the Serial number of HDD installed on Secondary IDE master. If no











hard disk or other devices are installed on Primary IDE master, then it will display a blank











line.

































Serial Number





This field displays the serial number of this unit.































UUID Number





UUID=32bytes
