Note:

The components identified with shading and a critical symbol ( Á ) are critical for safety. Replace only with part number specified.

Note:

The components identified by [ in this manual have been carefully factory-selected for each set in order to satisfy regulations re- garding X-ray radiation. Should replacement be required, replace only with the value origi- nally used.

S SERIES A COMMON PARTS LISTING

REF.NO.

PART NO.

DESCRIPTION



REMARK



R464



1-216-097-91

RES, CHIP

100K

5%

1/10W



R465



1-249-413-11

CARBON

470

5%

1/4W



R466



1-249-388-11

CARBON

3.9

5%

1/4W



R467



1-216-069-00

RES, CHIP

6.8K

5%

1/10W



R469





VARIANT (SEE VARIANT PARTS LIST)





R470



1-216-077-00

RES, CHIP

15K

5%

1/10W



R471



1-216-069-00

RES, CHIP

6.8K

5%

1/10W



R472





VARIANT (SEE VARIANT PARTS LIST)





R473



1-249-398-11

CARBON

27

5%

1/4W



R474



1-216-077-00

RES, CHIP

15K

5%

1/10W



R475



1-249-430-11

CARBON

12K

5%

1/4W



R476



1-249-430-11

CARBON

12K

5%

1/4W



R477



1-249-398-11

CARBON

27

5%

1/4W



R478



1-249-418-11

CARBON

1.2K

5%

1/4W



R479



1-249-418-11

CARBON

1.2K

5%

1/4W



R480



1-249-385-11

CARBON

2.2

5%

1/4W



R481



1-249-385-11

CARBON

2.2

5%

1/4W



R482



1-249-421-11

CARBON

2.2K

5%

1/4W



R483



1-249-421-11

CARBON

2.2K

5%

1/4W



R501



1-216-037-00

RES, CHIP

330

5%

1/10W



R502



1-216-061-00

RES, CHIP

3.3K

5%

1/10W



R503



1-249-426-11

CARBON

5.6K

5%

1/4W



R504

Á

1-215-915-11

METAL

470

5%

3W

R505



1-249-431-11

CARBON

15K

5%

1/4W

R506



1-215-861-00

METAL

47

5%

1W

R507



1-249-401-11

CARBON

47

5%

1/4W

R508



1-249-427-11

CARBON

6.8K

5%

1/4W

R509



1-247-750-11

CARBON

680

5%

1/2W



R510

Á

1-215-860-11

METAL

33

5%

1W

R511





VARIANT (SEE VARIANT PARTS LIST)





R512

Á

1-215-886-11

METAL

100

5%

2W

R515





VARIANT (SEE VARIANT PARTS LIST)



R516



1-216-057-00

RES, CHIP

2.2K

5%

1/10W

R517



1-249-415-11

CARBON

680

5%

1/4W

R518



1-216-073-00

RES, CHIP

10K

5%

1/10W

R519



1-249-411-11

CARBON

330

5%

1/4W



R521

Á

1-215-915-11

METAL

470

5%

3W



R523





VARIANT (SEE VARIANT PARTS LIST)





R524



1-249-429-11

CARBON

10K

5%

1/4W



R525



1-216-071-00

RES, CHIP

8.2K

5%

1/10W



R528



1-216-081-00

RES, CHIP

22K

5%

1/10W



R529





VARIANT (SEE VARIANT PARTS LIST)



[

R530 Á

1-208-808-11

RES, CHIP

12K

0.50%

1/10W

R531





VARIANT (SEE VARIANT PARTS LIST)



R532



1-208-760-11

RES, CHIP

120

0.50%

1/10W

R533





VARIANT (SEE VARIANT PARTS LIST)



R535





VARIANT (SEE VARIANT PARTS LIST)





R536

Á

1-249-377-11

CARBON

0.47

5%

1/4W



















R537

Á

1-249-377-11

CARBON

0.47

5%

1/4W

REF.NO.

PART NO.

DESCRIPTION



REMARK

R538



1-247-887-00

CARBON

220K

5%

1/4W

R541





VARIANT (SEE VARIANT PARTS LIST)



R542





VARIANT (SEE VARIANT PARTS LIST)



R543



1-249-377-11

CARBON

0.47

5%

1/4W

R546





VARIANT (SEE VARIANT PARTS LIST)



R547



1-215-457-00

METAL

33K

1%

1/4W

R549



1-215-437-00

METAL

4.7K

1%

1/4W

R550

Á

1-249-377-11

CARBON

0.47

5%

1/4W















R551

Á

1-215-873-00

METAL

4.7K

5%

1W

R552



1-216-069-00

RES, CHIP

6.8K

5%

1/10W

R553

Á

1-249-377-11

CARBON

0.47

5%

1/4W

R554



1-216-057-00

RES, CHIP

2.2K

5%

1/10W

R561



1-216-073-00

RES, CHIP

10K

5%

1/10W

R563

Á

1-216-351-00

METAL

1.5

5%

1W

R564



1-249-393-11

CARBON

10

5%

1/4W

R565

Á

1-215-890-11

METAL

470

5%

2W

R566



1-216-073-00

RES, CHIP

10K

5%

1/10W

R567

Á

1-249-385-11

CARBON

2.2

5%

1/4W

R568



1-216-073-00

RES, CHIP

10K

5%

1/10W

R569



1-216-073-00

RES, CHIP

10K

5%

1/10W

R570



1-216-097-91

RES, CHIP

100K

5%

1/10W

R571



1-216-081-00

RES, CHIP

22K

5%

1/10W

R572



1-216-081-00

RES, CHIP

22K

5%

1/10W

R573



1-216-097-91

RES, CHIP

100K

5%

1/10W















R574

Á

1-216-365-00

METAL

0.47

5%

2W

R575



1-216-113-00

RES, CHIP

470K

5%

1/10W

R576



1-216-073-00

RES, CHIP

10K

5%

1/10W

R577



1-216-097-91

RES, CHIP

100K

5%

1/10W

R578



1-208-784-11

RES, CHIP

1.2K

0.50%

1/10W

R579



1-208-842-11

RES, CHIP

330K

0.50%

1/10W

R580



1-249-441-11

CARBON

100K

5%

1/4W

R1009





VARIANT (SEE VARIANT PARTS LIST)



R1010





VARIANT (SEE VARIANT PARTS LIST)



R1101



1-216-049-91

RES, CHIP

1K

5%

1/10W

R1102



1-215-900-11

METAL

22K

5%

2W

R1103



1-216-051-00

RES, CHIP

1.2K

5%

1/10W

R1104



1-216-083-00

RES, CHIP

27K

5%

1/10W

R1105



1-216-689-11

RES, CHIP

39K

5%

1/10W

R1106



1-216-049-91

RES, CHIP

1K

5%

1/10W

R1107



1-216-065-91

RES, CHIP

4.7K

5%

1/10W

R1108



1-216-073-00

RES, CHIP

10K

5%

1/10W

R1109



1-216-019-00

RES, CHIP

56

5%

1/10W

R1110



1-216-019-00

RES, CHIP

56

5%

1/10W

R1111



1-216-019-00

RES, CHIP

56

5%

1/10W

R1115



1-216-045-00

RES, CHIP

680

5%

1/10W

R1117



1-249-425-11

CARBON

4.7K

5%

1/4W

R1118



1-249-425-11

CARBON

4.7K

5%

1/4W

R1120



1-216-057-00

RES, CHIP

2.2K

5%

1/10W

R1121



1-216-035-00

RES, CHIP

270

5%

1/10W

— 77 —
