Panasonic DMP-BDT210, DMP-BDT110 owner manual Reprogramming the remote control, Firmware updates

Page 15

Refer to the operating instructions of the hub or router.

WPS (Wi-Fi Protected Setup) is a standard that facilitates settings relating to the connection and security of wireless LAN devices. To see whether your Wireless router supports WPS, check the Wireless router operating instructions.

You can perform this setup anytime by selecting “Network Easy Setting” in the Setup menu. (> 32)

You can redo these settings individually using “Network Settings”. (> 32)

Do not use this unit or Wireless LAN adaptor to connect to any wireless network for which you do not have usage rights.

During automatic searches in a wireless network environment, wireless networks (SSID*) for which you do not have usage rights may be displayed; however, using these networks may be regarded as illegal access.

After performing network settings on this unit, the settings (encryption level, etc.) of the Wireless router might change. When you have trouble getting online on your PC, perform the network settings on your PC in accordance with the settings of Wireless router.

Please be aware that connecting to a network without encryption may result in the content of the communication being illegitimately viewed by a third party, or the leaking of data such as personal or secret information.

*An SSID (Service Set IDentification) is a name used by wireless LAN to identify a particular network. Transmission is possible if the SSID matches for both devices.

Reprogramming the remote control

If you have more than one Panasonic player/recorder and the remote control operates both products at once, you will need to change the remote control code on one product to prevent this occurrence. (> 33, “Remote Control Code”)

Firmware updates

Occasionally, Panasonic may release updated firmware for this unit that may add or improve the way a feature operates. These updates are available free of charge.

This unit is capable of checking the firmware automatically when connected to the Internet via a broadband connection. When a new firmware version is available, the following message is displayed.

New firmware is available.

Please update firmware in Setup.

To update the firmware

Settings



Press [HOME] > select “Setup” > select “Player



Settings” > select “Others” > [OK] > select “Firmware

&

Update” > [OK] > select “Update Now”

Connections

DO NOT DISCONNECT the unit from the AC power or



perform any operation while the update takes place.



After the firmware is installed, “FINISH” will be displayed on



the unit’s display. Unit will restart and the following screen



will be displayed.













The firmware was updated.





Current Version: x.xx



OK

RETURN

If downloading on this unit fails or this unit is not connected to the Internet, then you can download the latest firmware from the following website and burn it to a CD-R to update the firmware. http://panasonic.jp/support/global/cs/

(This site is in English only.)

To show the firmware version on this unit. (> 33, “System

Information”)

Downloading will require several minutes. It may take longer or may not work properly depending on the connection environment.

If you do not want to check for the latest firmware version, set “Automatic Update Check” to “Off”. (> 33)

VQT3B58 15

Image 15
