Panasonic DMP-BDT110, DMP-BDT210 Connecting to a broadband network, Connected to broadband

Page 10

STEP 3 : Connecting to a broadband network

The following services can be used when this unit is

For details about connection method, refer to the

connected to broadband.



instructions supplied with the connected equipment.

≥ Firmware can be updated (

15)



≥ You can enjoy BD-Live ( 19)



≥ You can enjoy VIERA CAST (

23)



≥ You can access other devices (Home Network) (

24)

LAN cable connection

10BASE-T/100BASE-TX

COMMUNICATION

CAMERALAN

LAN Cable

Broadband router, etc.

LAN Cable

Modem (Broadband) *Provided by ISP

Use category 5 or above straight LAN cables (STP) when connecting to peripheral devices.

Inserting any cable other than a LAN cable in the LAN terminal can damage the unit.

Wireless LAN connection

[BDT210] : Wireless LAN is built in. (There is no need to connect a Wireless LAN Adaptor.)

[BDT110] : Connect the Wireless LAN Adaptor DY-WL10 (optional).

[BDT110]

COMMUNICATION 10BASE-T/100BASE-TX

CAMERA

WIRELESS LAN

ADAPTORLAN

Wireless LAN Adaptor

Wireless router, etc.

LAN Cable

Modem (Broadband) *Provided by ISP

[BDT110] : Only the Wireless LAN Adaptor DY-WL10 (optional) can be used.

[BDT110] : Read the operating instructions for the Wireless LAN Adaptor DY-WL10 (optional) thoroughly when using it.

For up to date compatibility information on your Wireless router refer to http://panasonic.jp/support/global/cs/

(This site is in English only.)

For additional information about this unit refer to http://www.panasonic.com/consumer/support (For U.S.A.)

The unit is not compatible with public wireless LAN services provided in airports, stations, cafes etc.

[BDT110] : To simultaneously connect the Wireless LAN Adaptor DY-WL10 (optional) and a LAN cable, use the extension cable supplied with the DY-WL10.

10 VQT3B58
