Playing video contents

BD DVD CD SD USB

1 Insert the media.

If the menu is displayed, press [3, 4, 2, 1] to select the item. ( 16)

2 Press [3, 4] to select the title and press [OK].

When a message screen is displayed while playing back 3D compatible video software, play back in accordance with the instructions.

Other operations during play

These functions may not work depending on the media and contents.

Stop

Press [∫STOP].

The stopped position is memorized.

Resume play function

Press [1PLAY] to restart from this position.

The position is cleared if the tray is opened or you press

[∫STOP] several times to display “STOP” on the unit’s display.

On BD-Video discs including BD-J, the resume play function does not work.

To show menus

You can show Top Menu, Direct Navigator or Pop-up Menu.

Press [POP-UP MENU/TOP MENU].

Press [3, 4, 2, 1] to select the item and press [OK].

Pause

Press [;PAUSE].

Press [;PAUSE] again or [1PLAY] to restart play.

To show the status messages

While playing, press [STATUS].

The status messages give you information about what is currently being played. Each time you press [STATUS], the display information may change or will disappear from the screen.

e.g.BD-Video

T: Title, C: Chapter, PL: Playlist Elapsed time in the title

BD-Video

T1 C1 0:05.14

Play

0:20.52

Current position

Total time





DISCS CONTINUE TO ROTATE WHILE MENUS ARE DISPLAYED. Press [∫STOP] when you have finished playback to protect the unit’s motor, your television screen and so on.

Depending on media and contents, the display may change or may not appear.

DivX [BDT210_for_Canada] and MKV: Successive play is not possible.

It is not possible to playback AVCHD and MPEG2 video which have been dragged and dropped, copied and pasted to the media.

To save on electricity, the power is turned off automatically if there is no button operation for about 30 minutes when not playing back (such as when paused, displaying the menu, displaying still pictures, etc.). (Compatible with ENERGY STAR)

Search/Slow-motion

Search

While playing, press [SEARCH6] or [SEARCH5].

Music and MP3: The speed is fixed to a single step.

Slow-motion

While paused, press [SEARCH6] or [SEARCH5].

BD-Video and AVCHD: Forward direction [SEARCH5] only.

The speed increases up to 5 steps.

Press [1PLAY] to revert to normal playback speed.

Skip

While playing or paused, press [:] or [9].

Skip to the title, chapter or track you want to play.

Each press increases the number of skips.

Frame-by-frame

While paused, press [2] (2;) or [1] (;1).

Press and hold to change in succession forward or backward.

Press [1PLAY] to revert to normal playback speed.

BD-Video and AVCHD: Forward direction [1] (;1) only.

Changing audio

Press [AUDIO].

You can change the audio channel number or soundtrack language, etc.

Playback

VQT3B58 17
