Referencia rápida en

español (Spanish Quick Reference)

Conexiones básicas

Conexión a un televisor compatible con HDMI

HDMI IN

10BASE-T/100BASE-TX

Cable HDMI

UNICATION

AMERALAN

Conexión a un televisor con un cable para audio/vídeo

Cable de audio/vídeo

10BASE-T/100BASE-TX

R L

LAN

AUDIO IN VIDEO IN

Conexión a un televisor compatible con HDMI y a un amplificador/ receptor compatible con HDMI

HDMI IN

Cable HDMI

-TX

Altavoces multicanal

Amplificador/Receptor



HDMI IN

Cable HDMI

HDMI OUT

(ARC)



(ARC)

Conecte el cable de alimentación de CA por último

A una toma de corriente doméstica

AC IN

Cable de alimentación de CA (incluido)

Conéctelo cuando haya realizado el resto de conexiones.

Ahorro de energía

Esta unidad consume una pequeña cantidad de energía aunque esté ajustada en el modo de espera (Accionamiento rápido : Desactivado, aprox. 0,1 W). Para ahorrar energía cuando no vaya a utilizar la unidad durante mucho tiempo, desenchúfela de la toma de corriente.

Reproducción básica

Preparación

Encienda el televisor y seleccione la entrada de vídeo adecuada en el televisor.

1Pulse [Í POWER] para encender la

unidad.

Después de conectar su nuevo reprodutor y pulsar el botón de encendido, aparecerá la pantalla de la configuración básica.

2Inserte el medio.

Inicia la reproducción

Pulse [1PLAY].

Parada

Pulse [∫STOP].

La posición de detención se memoriza.

Función de reanudación de la reproducción

Pulse [1PLAY] para reiniciar la reproducción desde esta posición.

La posición se borra si se abre la bandeja o se pulsa

[∫STOP] varias veces para visualizar “STOP” en el visor de la unidad.

En los discos BD-Video incluidos los BD-J, la función de reanudación de la reproducción no funciona.

Pausa

Pulse [;PAUSE].

Pulse [;PAUSE] otra vez o [1PLAY] para reiniciar la reproducción.

Búsqueda/Cámara lenta

Búsqueda

Durante la reproducción, pulse [SEARCH6] o [SEARCH5].

Música y MP3: La velocidad está fija en un paso.

Cámara lenta

Durante la pausa, pulse [SEARCH6] o [SEARCH5].

BD-Video y AVCHD: Sólo dirección en avance [SEARCH5].

La velocidad aumenta hasta 5 pasos.

Pulse [1PLAY] para recuperar la velocidad de reproducción normal.

Salto

Durante la reproducción o la pausa, pulse [:] o [9].

Salta hasta el título, capítulo o pista que desee reproducir.

Cada pulsación aumenta el número de saltos.

Reference

VQT3B58 43
