Special Features

Remote Control Functions

Remote A/B Code Switching

The remote control is capable of controlling two JVC video recorders independently; one set to respond to the remote control's A code control signals and another set to respond to B code control signals. The remote control is preset to send A code signals because your video recorder is initially set to respond to A code signals. You can easily modify your video recorder to respond to B code signals.

ASet remote control code for remote control

APress and hold VCR.

BPress the number key “2”. C Press OK, and release VCR.

The remote control now can transmit B code control signals.

BCheck remote control code for decorder

Press and hold 4 on the recorder for more than 5 seconds while the recorder is turned off. The code currently set appears on the display panel.

CChange code for recorder

Press any key on the remote control. The recorder now responds to B code control signals.

To control two recorders with the same remote control

You can control two JVC recorders by switching the remote control code for the remote control between A and B ( step 1), keeping two recorders to different control codes.

To change only the remote control code for the remote control, DO NOT perform steps 2 and 3.

NOTE:

To set the recorder back to respond to A code signals, repeat the same procedure as shown above except pressing number key "1" instead of "2" in step 2 of 1.

Control Your TV Using Additional Buttons

Use the number keys, and the p button, & button or # button to select the TV's channel.

With televisions under Code 01, 02, 07, 08, 10, 11, 14, 20, 22, 23, 24, 25, 27, 33, 35, 38, 40 or 42, the p button corresponds to the 1-digit/2-digit entry switching button (often labelled – /– –) of your TV's remote control.

With televisions under Code 01, 16, 28, 29, 34 or 39, the & button corresponds to the 10 + button, and the # button corresponds to the 20 + button of your TV's remote control.

NOTE:

The way these buttons are used is determined by your TV. Use these buttons as instructed for your TV's remote control.

TV Multi-brand Remote Control

Your remote control can operate the basic functions of your TV set. In addition to JVC TVs, other manufacturer's TVs can also be controlled.

ATurn on TV

Turn on the TV using the Power button on the TV or its remote control.

BSet TV brand code

APress and hold TV.

BPress the number keys to enter your unit’s brand code.

CPress OK, and release TV. Check if the TV's power goes off as it

should. If it does, try other operations ( step 2).

Once you have set the remote control to operate the TV, you don't have to repeat this step until you replace your remote control's batteries.

Some TV brands have more than one code. If the TV does not function with one code, try entering another.

COperate TV

First, press TV to set the remote control to TV mode, then press one of the following buttons: 1, TV/VCR, TV PR +/–, ^ (TV Muting), TV %+/– (TV volume), and the number keys.

For some brands, you must press OK after having pressed the number keys to enter a channel number.

IMPORTANT

Although the provided remote control unit is compatible with JVC televisions, as well as many other models, it may not work with your TV, or in some instances, may have limited function capability.

TV BRAND

CODE

TV BRAND

CODE

NAME



NAME











JVC

01, 23, 24, 25

MITSUBISHI

03

AIWA

36

MIVER

29

BEIJING

22

NEC

20

CCE

02

NOBLEX

22

CHANGHONG

34

NOKIA

31

DAEWOO

17, 37

PANASONIC

04, 11

FERGUSON

27

PEONY

34, 38, 39

FINLUX

30

PHILICO

10, 17, 21

FUNAI

32

PHILIPS

02, 42

GRADIENTE

15

SAMSUNG

12, 33, 34, 35

GRUNDIG

19

SANYO

13, 16

HITACHI

10

SHARP

06

ITT

28

SONY

07

JINXING

38

TCL

41

KONKA

40

THOMSON

26

LG/GOLDSTAR

18

TOSHIBA

08, 14









ATTENTION

The remote control can operate not only the video recorder but also some of your TV, cable box, satellite receiver and DVD.

To operate your video recorder, first press the VCR button to set the remote control to the Video mode.

To operate your TV, first press the TV button to set the remote control to the TV mode.

To operate your satellite receiver, cable box or DVD, first press the CABLE/SAT/DVD to set the remote control to the satellite receiver, cable box or DVD mode.

— 17 —

Image 17
