Philips HTB3525B user manual Change settings, Language settings, Picture and video settings

Page 25

6 Change settings

The Blu-ray Surround Base settings are already configured for optimal performance. Unless you have a reason to change a setting, we recommend that you keep the default setting.

Note

•• You cannot change a setting that is grayed out.

•• To return to the previous menu, press . To exit the menu, press .

Language settings

1 Press .

2 Select [Setup], and then press OK.

3 Select [Preference], and then press OK.

4 Press the Navigation buttons and OK to select and change:

[Menu language]: Select a display language for menu.

[Audio]: Select an audio language for discs.

[Subtitle]: Select a subtitle language for discs.

[Disc menu]: Select a menu language for discs.

Note

•• If your preferred disc language is not available, select [Others] from the list, and enter the 4-digit language code found at the end of this user manual (see 'Language code' on page 37).

•• If you select a language that is not available on a disc, the Blu-ray Surround Base uses the default language of the disc.

Picture and video settings

1 Press .

2 Select [Setup], and then press OK.

3 Select [Video], and then press OK.

4 Press the Navigation buttons and OK to select and change:

[Tv type]: If the video does not appear correctly, select a TV type (color system).

[TV display]: Select a picture format to fit the TV screen.

[HDMI video]: Select the resolution of video signal that is output from HDMI OUT (ARC) on your Blu-ray Surround Base .To enjoy the selected resolution, make sure that your TV supports the selected resolution.

[HDMI Deep Color]: Recreate the natural world on your TV screen by displaying vivid images using billion colors.Your Blu-ray Surround Base must be connected to a Deep Color enabled TV through an HDMI cable.

[Picture settings]: Select pre defined color settings for the video display.

[Watch 3D video]: Set HDMI video to support 3D or 2D video.

[Closed Caption]:Turn on or off the display of sound effects in subtitles (applicable only when a disc and a TV support this feature).

Note

•• If you change a setting, make sure that the TV supports the new setting.

E n g l i s h

EN 23
