Philips HDR1000/01 specifications MP3 Playback Track Selection, Display Information, Program

Page 37

DVD OPERATION

MP3 PLAYBACK

TRACK SELECTION

When you insert a CD with MP3 files in the HDR1000, the MP3 menu will appear on the TV screen.

In stop mode, press K or L button to select the desired Album or Track.

•

To play a choosen track, press PLAY button or OK



button.

•

When you select an album, press OK button. The

Press SEARCH MODE button during playback.

•The SEARCH menu will appear.

•The current track will be highlighted.

ALBUM NAME

+ALBUM01

TRACK11

TRACK12

TRACK13

TRACK141/15

SELECT:

/

ENTER:

RETURN:



START: PLAY



track selection screen will appear. Press K or L



button to select the desired track, then press PLAY



button or OK button.

•

Choose FIRST PLAY to start playback from the



beginning of the listed tracks.

•

Press TITLE button to return to the first item.

Press STOP button to stop playback.

NOTE:

•Folders are known as Albums; files are known as

DISPLAY INFORMATION

You can check the MP3 files during playback.

Press DISPLAY button during play- back.

•The playing track will be highlighted.

Press DISPLAY button again to show the elapsed playing time at the top on the TV screen.

T - indicates Track repeat

A - indicates Album (folder) repeat

D - indicates Disc repeat

Press K or L button to select a desired track.

Press PLAY button to start playing.

Press RETURN button or SEARCH MODE button to exit.

RANDOM PLAYBACK

Press MODE button twice during playback is stopped.

Press PLAY button to play the tracks in random order.

PROGRAM

Press MODE button during playback is stopped.

Press DISPLAY button again to exit.

Press K or L button to select a track, then press OK button.

•Press CLEAR button to erase the incorrect input.

PROGRAM - ALBUM01

+ALBUM11

TRACK11

+ALBUM12



TRACK11



TRACK12



TRACK13



1/11

1/1

START: PLAY

DELETE: CLEAR

RANDOM: MODE

EXIT: RETURN

Press PLAY button to start pro- grammed playback.

– 38 –

EN / 2A01

Page 36 Page 38
Image 37
