Panasonic SV-AS3 operating instructions Playing Still Pictures on the Slide Show, ¿ mark

Page 52

Playback (continued)

Playing Still Pictures on the Slide Show

Still pictures are automatically played in sequence. This function is suitable for making a story with still pictures.

1Set the mode to [Picture] mode. (P41)

2Press the [MENU] button and then set the item with the Jog Ball. (P18)

Slide show

l	Play slide show

l

Slide show	Plays slide shows with audio (P50) created
(with audio)	on this unit.

Slide show	Plays all pictures (in the order of the file
(all pictures)	number).

SD Slide	Plays slide shows set on the supplied
show	software SD Viewer.

Slide show	Plays slide show pictures registered as
(¿ mark)	“Favourite” (P49).

– A slide show starts.

•Press the Jog Ball to stop the playback halfway.

≥You can set the pictures which will be played as a slide show in

SD Viewer. On this unit, pictures cannot be played in the interval set in SD Viewer.

≥You can adjust the volume with the Volume button on the remote controller during the slide show (with audio). (The volume control screen does not appear.)

≥It may take time to display the slide show (with audio) since the opening screen appears during a preparation for playback. However,

52	this is not a malfunction.

VQT0Q47
