Panasonic NV GS 330 operating instructions Using the DV Cable for Recording Digital Dubbing

Page 46

Edit mode

≥If you record (dub) images onto another video device and then play them back on a wide- screen TV, the images may be stretched vertically. In this case, refer to the operating instructions for the device that you are recording

(dubbing) to or read the operating instructions for the TV and set to 16:9 (full).

≥For more information, refer to the operating instructions for your TV set and recorder.

≥When you do not need functional indications or date and time indication, respectively set [SETUP] >> [DISPLAY] >> [OFF] or set [BASIC]

>>[DATE/TIME] >> [OFF] in the Tape Playback Mode.

(When you connect the movie camera and a recorder with the DV cable, these indications may not appear.)

ªWhen neither image nor sound from the movie camera is output to the TV set

≥Check that the plugs are inserted as far as they go.

≥Check the [12bit AUDIO] settings. (-48-) ≥Check the connected terminal.

Using the DV Cable for Recording (Digital Dubbing)

By connecting other digital video equipment with DV terminal and the movie camera by using the DV cable VW-CD1E (optional) 1, high-image- quality dubbing can be done in digital format. ≥Set to Tape Playback Mode.

(Player/recorder)

1Connect the movie camera and digital video equipment with the DV cable.

1

2Set [ADVANCED] >> [REC STDBY] >> [YES]. (Recorder)

≥You do not have to follow this step when the remote control is used in the digital dubbing.

3Start playback. (Player)

4Start recording. (Recorder)

When operating with the main unit: Move the joystick up to select [¥/;] icon.

When operating with the remote control:

While pressing the [¥REC] button on the remote control, press the [PLAY 1] button.

5Move the joystick up to select the [¥/;] icon again or press the [;] button on the remote control to stop recording. (Recorder)

6Stop playback. (Player)

46

VQT1L48
