AXIS T90B Series

LED Indicators

There are three colored LED indicators on the base of the illuminator which provide operating and status information. The color status depends on the current operating mode:

Programming Mode

Normal Operating Mode

Programming Mode

LED Indicator

Indicated Behavior





Solid Green

Power on





Flashing Green

Remote control IR receiver error





Solid Amber

Illuminator receiving valid



command from remote control





Flashing Amber

Illuminator in Programming Mode





Solid Red

Internal LED error





Flashing Red

Input voltage supply error*





Normal Operating Mode







LED Indicator

Indicated Behavior





Solid Green

Power on





Flashing Green

Remote control IR receiver error





13
