Axis Communications 241Q user manual Html Examples, External Video, Sequence Mode, Output Buttons

Page 26

26AXIS 241Q/241S - Live View Config

6.Enter the cgi link: http://192.168.0.125/axis-cgi/com/ptz.cgi?camera=1&continuouspantiltmove=0,0

These links appear in the web interface and can be used to control the PTZ camera

For more information on VAPIX®, Axis Communications’ powerful API, see the Developer pages at the Axis web site www.axis.com/developer

See also the section on PTZ, on page 33.

Output Buttons

These buttons are used to control the outputs on the Axis video server and thus the equipment connected to them, such as switching a light on or off:

The Pulse button activates the port for a defined period

Active/Inactive displays two buttons, one for each action (on/off)

HTML Examples

Live video from the Axis video server can be added to your own web page.

Select the preferred Video Format from the drop down list. The available options are Motion JPEG, MPEG-4 using AMC, and MPEG-4 using QuickTime.

For the second option (MPEG-4 using AMC), a separate MPEG-4 license is required for each viewer.

The Motion JPEG selection has additional settings for Image Type, Image size and other optional settings for configuring the video stream to suit your web page. Click Update when satisfied.

The video server then generates the required source code for your configuration. Copy this code and paste it into your own web page code.

External Video

You can add links to other Axis network devices available over the network. These sources can be displayed on the Live View page, just as if they were video sources connected directly to the Axis video server.

Click the Add... button to open the External Video Source Setup dialog, to define the settings. Click the online help button for more details. This is an example of a path to an external video source:

http://192.168.0.125/axis-cgi/mjpeg/video.cgi

Sequence Mode

The Live View page can be configured to rotate through the internal and selected external video sources, in order or at random. Select the desired video sources and enter the time in seconds to display each source (up to 59 minutes). Click Save.

The Sequence buttons appear on the Live View page to enable the viewer to start and stop the sequence mode.

Image 26
