2.Tighten two screws on each side.
Use any of binding screws (4 mm ⋅ 3 mm), binding screws (5 mm ⋅ 6 mm) or flush surface screws (5 mm ⋅ 6 mm), depending on the shape of screw holes in the bracket.
Screw
Dashboard or Console
Factory radio mounting bracket
Fastening the front panel
If you do not plan to detach the front panel, the front panel can be fastened with supplied screws.
•Fix the front panel to the unit using screws after removing the trim ring.
Screws
Installing the remote control unit
| English | |
When not using the remote control | ||
| ||
unit, secure it with velcro tape to pre- |
| |
vent it from moving. |
|
•Thoroughly wipe off the surface before affixing the velcro tape.
Remote control unit
Velcro tape (small)
(hard)
Velcro tape (small) (soft)
