NordicTrack NTC07940 user manual HOW to Connect Your Home Stereo HOW to Connect Your Computer

HOW TO CONNECT YOUR HOME STEREO

Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B.

HOW TO CONNECT YOUR COMPUTER

Note: If your computer has a 1/8” LINE OUT jack, see instruction A. If your computer has only a PHONES jack, see instruction B.

A. Plug one end of the audio cable into the jack beneath the console. Plug the other end of the cable into the adapter. Plug the adapter into the LINE OUT jack on your stereo.

A
CD
VCR
Amp	LINE OUT
LINE OUT
Adapter
Audio Cable

B. Plug one end of the audio cable into the jack beneath the console. Plug the other end of the cable into the adapter. Plug the adapter into an RCA Y-adapter (available at electronics stores). Next, remove the wire that is currently plugged into the LINE OUT jack on your stereo and plug the wire into the unused side of the Y-adapter. Plug the Y-adapter into the LINE OUT jack on your stereo.

B	CD
	VCR
	Amp LINE OUT
	RCA
Audio	Y-adapter
Cable	Adapter
Wire removed from
LINE OUT jack

A. Plug one end of the audio cable into the jack beneath the console. Plug the other end of the cable into the LINE OUT jack on your computer.

A

LINE OUT

Audio

Cable

B. Plug one end of the audio cable into the jack beneath the console. Plug the other end of the cable into a 1/8” Y-adapter (available at electronics stores). Plug the Y-adapter into the PHONES jack on your computer. Plug your headphones or speak- ers into the other side of the Y-adapter.

B
	PHONES
	1/8”
Audio Cable	Y-adapter
Headphones/Speakers

18
