Tascam 788 manual Troubleshooting, doesn’t play when I hit Play, is out of time from the source

Page 31

31

Troubleshooting (Continued)

Section VII

The 788 doesn’t play when I hit PLAY.

Press HOME/ESC, and check to see if time is rolling. If time is rolling, you’re probably in a quiet part of the song. Go to a section of the song where some audio has been recorded.

If the play light flashes when you press PLAY, that means it is waiting for MIDI Time Code to start. Press

MENU, select ,

and choose . The first

parameter is . If that is set to , change it to .

Make sure that the SYNC SRC is set to INT. If it is set to EXT, the 788 will wait for time code to follow. Waiting for time code is indicated by a flashing PLAY LED.

When I lock the 788 to another source, the pitch wavers and the sound cuts in and out.

–OR-

The 788 is out of time from the source.

Chances are you have different MTC frame rates selected for the two machines, or the machines might be running too fast or too slow.

To check the frame rate on the 788, press MENU,

select , and choose . Make sure the frame rate is the same on both your master machine, and your 788. If you are only experiencing minor variation over time and your frame rate is a variation of 30 or 29.97, pay particular attention to the drop and non-drop status of the frame rates.

If the two machines just seem to be out of time from each other, check the same screen for MTC offsets that don’t belong. (If the tracks were recorded with an offset, the offset must be maintained through the entire project. Otherwise you’ll probably want to set the MTC offset to 00:00:00:00.

Another possible cause would be that the machines are not locked with time code, but instead are reacting to each other with MIDI Machine Control. Make sure you have MIDI Time Code enabled; you may want to disable MIDI Machine Control. To turn off MIDI

Machine Control, press MENU, select , and

choose . Under the tab, choose to be .

TASCAM 788 Operational Tutorial • 8/2000 Edition

Troubleshooting

Page 30 Page 32
Image 31
Page 30 Page 32
Contents Operational Tutorial Table of Contents CREATE, Save a Song QuickStart First SessionSection Intro & Initial SET-UPMixing Tracks QuickStart First SessionBouncing Tracks Basic EditingFinal Thoughts Routing Inputs & Tracks Mixer FunctionsMixing Section Overview TopicsEQ Section Mixer FunctionsChannel Strip Channel Send & Return InsertEffect & Aux Sends Mixer FunctionsFader, Pan & Linking Channels Channels already assigned to the input submixer Input SubmixerTrack CUE Monitor SectionAssign MAP Routing & Scene LibrariesFader Matching Editing Functions Recording & Editing FunctionsRecording Overview Song MenuLocate Points Recording & Editing Functions More Locate ResolutionVirtual Tracks Punch IN/OUT & Auto PunchEdit Functions Definitions Editing FunctionsAssigning Virtual Tracks Naming Virtual TracksPitch Control / SSA Recording & Editing FunctionsFunction cannot be undone MENU, select , then Formatting DrivesTargeting Record Drives Order to format a drive Press MENU, selectRouting Effects Built-in Effect ProcessingEffect Overview EffectEXIT/NO Built-in Effect Processing SectionControlling Effects Effect TypesFinal Notes Effects Built-in Effect ProcessingCompression Selecting Items For Naming Naming ProcedureAssigning Names Naming OverviewEditing the User Word List Assigning NamesMidi Functions Overview Midi FunctionsMidi Clock Midi Time Code MTC Midi FunctionsMidi Machine Control MMC Metronome SettingsMidi Metronome Settings BUILT-IN MetronomeMidi Automation Midi FunctionsMMC with Midi Sequencers Can’t hear the 788’s metronome Trouble-ShootingCan’t hear anything I’ve assigned to the input Submixer Troubleshooting SectionEverything is in mono Can’t hear any stereo effects788 doesn’t play when I hit Play Troubleshooting788 is out of time from the source Tips & Tricks Overview Tips & TricksTips and Tricks Operational Tutorial
Related manuals
Manual 8 pages 14.6 Kb

788 specifications

The Tascam 788 is a portable digital audio workstation that made a significant impact in the realm of music production and recording. Launched in the early 2000s, the 788 is particularly well-regarded for its blend of portability, versatility, and quality. Aimed primarily at musicians, podcasters, and sound designers, this device caters to those who need a reliable means to capture high-fidelity audio in various environments.

At the heart of the Tascam 788 is its ability to record up to eight tracks simultaneously, offering a total of 24 tracks for playback. This multi-track capability allows users to layer instruments and vocals, creating rich, full-bodied productions. Each track supports high-resolution recording at 24-bit/96kHz, providing professional quality that rivals many studio setups. The onboard effects and mixing capabilities further enhance its functionality, allowing users to manipulate their recordings in real-time.

The Tascam 788 features a user-friendly interface with a large LCD screen, making navigation straightforward. It includes a variety of inputs, including XLR and TRS, making it flexible for different microphone types and instruments. The device also has built-in phantom power for condenser mics, ensuring that you can capture clear audio with minimal external setup.

One of the standout features of the Tascam 788 is its integrated CD-RW drive, allowing users to burn audio directly onto CDs without needing a computer. This is particularly useful for artists wishing to create demo discs or share their music with others quickly and easily. Additionally, the presence of a USB port means that users can connect the device to a computer for further editing and file management, making it easy to integrate with digital audio software.

The Tascam 788 employs a compact and rugged design that is ideal for mobile musicians and recording engineers. Weighing less than many of its contemporaries, the device can be easily transported, making it suitable for on-the-go recording sessions. The long battery life adds to its portability, enabling recordings without the constant need for a power source.

In summary, the Tascam 788 stands out as a versatile tool for both novice and professional audio creators. With its multi-track recording capabilities, high-quality audio, and portable design, it remains a beloved choice for those looking to capture and produce music seamlessly and effectively. Whether in a studio or on the road, the Tascam 788 brings together essential features that cater to the diverse needs of today's audio artists.
