Skype Digital Enhanced Cordless Communication manual Extra Setting, Skype Function

Page 14

6.After a while, when the handset finds the base unit, it goes back to the standby mode.

To de-register a handset

You may need to do this if you have more than one handset registered to your base unit and you need to replace a faulty handset.

1.Select <de-register> under REGISTRATION mode.

2.Press Left key, then key in the PIN (default 0000).

3.Press Left key, then key in the number of the handset you want to de-register.

4.Press Left key to confirm.

Note: You cannot de-register the handset you are currently using.

To register a USB dongle

1.Press and hold the Handset locator button on the base unit for a while, until you hear "beep" sound twice continuously;

2.Insert the USB dongle into your PC USB port, the LED will be blinking.

3.Use a paper clip or a pencil tip to depress and hold the reset button of dongle for 2~3 seconds, then release and you will hear a confirmation tone from Base unit.

4.Once registered successfully, the LED on the dongle will be turned on permanently.

Extra Setting

To Set Alarm Time

1.Select EXTRA under menu mode;

2.Select < Alarm Set > under EXTRA mode;

3.Press Left key, then press Scrolling button to goes to location ON;

4.Press Left key, then key in the time;

5.Press Left key to save;

To Set Clock Time

1.Select < Clock Set > under EXTRA mode;

2.Press Left key, then key in the time;

3.Press Left key to save;

To Set Date

1.Select <Date Set > under EXTRA mode;

2.Press Left key, then key in the date;

3.Press Left key to save;

SKYPE Function

To Make a SkypeOut Call

SkypeOut allows you to use your Internet connection to call ordinary telephones and mobile telephones worldwide.

Enter the telephone number you wish to call and the symbol “SkypeOut” appears on the left bottom of display, then press Left key to place call.

Note: The Skype software must be activated on your PC in order to perform SkypeOut and Skype™ calls. To perform SkypeOut calls you also need to set up a user account and top up with call credit at www.skype.com

13
