Panasonic KX-TS840MX Desk mount setup, Low desk position default High desk position

Page 17

Useful Information

Desk mount setup

This unit can be used in 2 positions.

Low desk position (default)

High desk position

– You can adjust the wall mount adaptor to slope this unit.

Changing to the high position

1.Press the tab in the direction of the arrow (A), then remove the adaptor (B).

2.To attach the adaptor to high (), push it in the direction of arrows ((A) and (B)) as shown.

2

1

1

2B

1

1

11

2 2

A1

A1

2

2

17
