Page 13

Operating Instructions and Parts Manual

AL2710

Airless Paint Systems

Maintenance (Cont.)

5.Place a 1/4” allen wrench into insert and unscrew insert from piston. Clean piston and seat, and then inspect them carefully for wear and damage. Replace these parts if needed.

REASSEMBLY

1.To reassemble the piston assembly, place in block using dowel pin and hold in vise. Install ball, seat and O-Ring in this order. Use blue loctite 242 on retainer and screw into piston. Tighten to 20 ft. lbs.

NOTE: For pumps manufactured prior to Year 2000 Install, Piston Rod Assembly PN 331-093 Only. Assembly PN 331-093 includes all new valve parts that will update the old pumps to present design.

2.Lubricate piston rod with oil or multi-purpose grease.

3.Soak leather packings in throat seal oil or other light-weight oil for 10- 15 minutes.

4.Reassemble all parts onto piston rod in following order (see page 24 for picture):

a.Start with lower male adapter.

b.Five V-Packings, "V" inverted.

c.Female adaptor.

d.FiveV-Packing, "V" up.

e.Male Adaptor.

f.Slide on tube spacer.

g.Three Belleville Springs starting with the first spring facing down

(

)

), second one facing up (

(

),

and the third one facing down



(

)

).





h. Upper male adaptor.

i. Five V-Packings, "V" inverted.

j. Place O-rings onto seal holder.

k. Lubricate outside diameter of V-

packings with white lithium or multipurpose grease.

l. Slide seal holder (2) over Upper Packing Set.

m. Lubricate threads on inside of pump body with white lithium or Multipurpose grease.

5.Hold pump body in one hand upside down and slide entire piston assembly with packings up into pump body, while rotating piston and packing assembly.

6.Install packing nut, handtight only. Push piston rod up to its upper position.

7.Connect the fluid pump onto Unit as per "Fluid Pump Reinstall" Procedures on page 11.

www.chpower.com

13
