4Removal and replacement preliminary requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

Flat-bladed screw driver

Magnetic screw driver

Phillips P0 screw driver

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

NOTE: As you remove each subassembly from the computer, place the subassembly (and all accompanying screws) away from the work area to prevent damage.

Plastic parts

CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use care when handling the plastic parts. Apply pressure only at the points designated in the

maintenance instructions.
