Samsung RF26VABBP Using the Cool Select Pantry RF267, Using the tilting pocket, Selection Button

Page 29

USING THE COOL SELECT PANTRY™ (RF267)

The Cool Select Pantry™ is a full-width drawer with adjustable temperature control. This pantry can be used for large party trays, deli items, pizza, beverages or miscellaneous items.

There is a temperature control which can adjust the amount of cold air allowed into the pantry.

The control is located on the right side of the pantry.

Selection Button

1. When “Deli” is selected, the temperature of the pantry can

be kept around 41°F(5°C). This feature helps keep food

fresh for a long time.

Pantry temperature can be maintained under recommended temperature setting(Freezer:-2°F, Fridge:38°F)

2. When “Fresh” is selected, the temperature of the pantry can be kept around 38°F(3°C). This feature helps keep food fresh for a longer time.

Pantry temperature can be maintained under recommended temperature setting (Freezer : -2°F, Fridge : 38°F)

3. When “Chilled” is selected, the temperature of the pantry can be kept around 34°F(1°C). This feature also helps keep

meat or fish fresh for a longer time.

Pantry temperature can be maintained under recommended temperature setting (Freezer : -2°F, Fridge : 38°F)

Deli

Fresh

Chilled

· pineapple

· cucumbers

· steaks

· lemon

· apples

· hard cheeses

· avocado

· oranges

· cold cuts

· potato

· grapes

· bacon



· zucchinis

· hot dogs



· corn



Fruits and vegetables may be damaged when the “chilled” mode is set.

Do not store lettuce or other leafy produce in this pantry.

CAUTION Do not store glass bottles in this pantry. If they are frozen, they can break and cause personal injury.

USING the tilting pocket

The Tilting Pocket can be used to store up to a 16” pizza if you place it shown in the illustration.

OPERA02 TING

Operating _29
