Operating your SAMSUNG French Door Refrigerator

REMOVING THE REFRIGERATOR ACCESSORIES

1. Door Bins & Dairy Compartment

To remove - Simply lift the bin up and pull straight out.

To relocate - Slide it in above the desired location and push down until it stops.

Injury may occur if the door bins are not firmly assembled.

CAUTION Do not allow children to play with bins. Sharp corners of the bins may cause injury.

Do not adjust a bin full of foods.

2. Tempered Glass Shelves

To remove - Tilt up the front of the shelf in the direction

1

shown ( 1 ) and lift it up vertically (

2 ).



Pull the shelf out.



2

To relocate - Tilt the front of the shelf up and guide the shelf hooks into the slots at a desired height.

Then lower the front of the shelf so that the hooks can drop into the slots.

The Tempered Glass shelves are heavy.

CAUTION Use special care when removing them.

3. Vegetable & Fruit Drawers

To remove - Pull the drawer out to full extension.

Tilt up the front of drawer and pull straight out.

To relocate - Insert the drawer into the frame rails and push back into place.

The glass shelf over the drawer is not firmly secured. Be careful

CAUTION when lifting.

Do not open the drawer while the pantry is open.

It may cause scratch or breakage to it’s cover.

4. Deli Drawer (RF26V)

To remove - Pull the Deli Drawer out to the stop position

Lift the Deli Drawer up and past the stop.

30_ Operating
