Samsung RF26VABBP Removing the Freezer Accessories, Tilting Pocket, Auto Pull out Drawer

Page 32

Operating your SAMSUNG French Door Refrigerator

REMOVING THE FREEZER ACCESSORIES

1. Tilting Pocket

To remove - Pull the brackets( 1 ) upward until you hear a clicking sound and remove the pocket

To replace - Hook the ends of the pocket into both brackets ( 1 ) and push down until it locks into place.

1

2. Auto Pull out Drawer

To remove - Pull the drawer out to full extension.

Tilt up rear of drawer and lift straight out.

To relocate - Place the drawer onto the rails by tilting it up. Lower the drawer into place until it is horizontal and slide the drawer in.

1

2

3. Freezer Drawer Bin

To remove the drawer - Pull the drawer out fully.

Tilt up the rear of the bin and lift it out to remove.

To replace the drawer - Place the bin into the rail assembly.

To remove the divider - Pull the divider straight up.

To replace the divider - Hook the top corners of divider over the hole of the bin.

32_ Operating
