Alto-Shaam AS-250 manual Trouble Shooting, To test probe and air sensor

Page 18







S E R V I C E















TROUBLE SHOOTING

















Error









Code

Description

Possible Cause















E-10

Cavity air sensor shorted

Cavity air sensor reading < 5°F. Verify sensor integrity.









See sensor test instructions below.





E-11

Cavity air sensor open

Cavity air sensor reading > 517°F. Verify sensor integrity.





See sensor test instructions below.













E-20

Product probe is shorted

Product probe reading < 5°F. Verify sensor integrity.





Oven will cook in time only

See sensor test instructions below.











E-21

Product probe is open

Product Probe reading > 517°F. Verify sensor integrity.





Oven will cook in time only

See sensor test instructions below.











E-30

Under temperature

Unit has not reached set-point for more than 90 minutes.









Unit has been higher than 25°F above the maximum cavity set-point for





E-31

Over temperature

more than 2 minutes. Note: Holding Cabinets with this error code are









more than 145°F higher than the maximum set-point.





E-50

Temp. measurement error

Contact factory.





E-51

Temp. measurement error

Contact factory.





E-60

Real time clock error

Data set to factory default. Ensure that date and time are correct if applicable.





E-61

Real time clock error

Contact factory.





E-78

Voltage low

Voltage below 90 VAC on a 125 VAC unit, or below 190 VAC on a









208-240 VAC unit. Correct voltage.





E-79

Voltage high

Voltage over 130 VAC on a 125 VAC unit, or over 250 VAC on a









208-240 VAC unit. Correct voltage.





E-80

EEPROM Error

Ensure that all temperatures and times are properly set.









Contact factory if problem persists.





E-81

EEPROM Error

Contact factory.





E-82

EEPROM Error

Contact factory.





E-83

EEPROM Error

Contact factory.





E-85

EEPROM Error

All timers, if previously on, are now off. Possible bad EEPROM.





E-86

EEPROM Error

Stored HACCP memory corrupted. HACCP Address reset to 1. Possible bad









EEPROM. Contact factory if problem persists.





E-87

EEPROM Error

Stored offsets corrupted. Offsets reset to 0. Control may need a recalibration.









Possible bad EEPROM. Contact factory if problem persists.





E-88

EEPROM Error

All timer set-points are reset to 1 minute. Timers, if previously on, are now









off. Possible bad EEPROM.





E-90

Button stuck

A button has been held down for >60 seconds. Adjust control. Error will









reset when the problem has been resolved.





E-dS

Datakey error

Datakey digital signature incompatible. Cycle power, and install compatible









Datakey if error persists.





E-dT

Datakey error

Datakey incompatible with control. Install compatible Datakey.





E-dU

Datakey unplugged

Install Datakey and cycle power to control to clear error.



Note: If in doubt, always cycle the power to the control and contact factory if the problem persists.

To test probe and air sensor:

Test probe and air sensor by placing sensor in ice water bath and using an ohmmeter set on the ohm scale. The reading should be 100 ohms resistance. If it is more than 2 ohms higher or lower, sensor needs to be replaced.
