Allied Air Enterprises Upflow Confined Space / Outdoor Air, From Attic & Crawl Space

Models: Downflow or Horizontal 2 Stage Heat Variable Speed Gas Fired Non-Condensing Warm Air Furnace Upflow

1 28

Download 28 pages 32.15 Kb

Page 10

FROM ATTIC

Figure 4	When horizontal ducts are used to supply air from the
CONFINED SPACE / OUTDOOR AIR	outdoors, they must be of the same cross sectional area
	as the free area of the openings to which they connect.
FROM ATTIC	The minimum dimension of rectangular air ducts must not
	be less than 3 inches. Each opening must have a free
	area of not less than one square inch per 2,000 Btu per
	hour of total input of all appliances within the "Confined
	Space". These openings must be located 12 in. from the
	top and bottom of the furnace area. Neither opening can
	be blocked at any time (See Figure 6).
	Figure 6
	CONFINED SPACE / OUTDOOR
	AIR THROUGH HORIZONTAL DUCTS

Figure 5

CONFINED SPACE / OUTDOOR AIR

FROM ATTIC & CRAWL SPACE

For an attic installation it is important to keep insulation 12" or more away from any furnace openings. Some types of insulating materials may be combustible.

Furnaces installed with combustion air drawn from a heated space which includes exhaust fans, fireplaces, or other devices that may produce a negative pressure should be considered confined space installations.
