J-Micron eSATA/PATA Controller [Enabled]

設定值有:[Enabled] [Disabled]

Controller Mode [IDE]

設定值有:[RAID] [IDE] [AHCI]

Serial Port1 Address [3F8/IRQ4]

本項目可以設定序列埠 COM 1 的位址。設定值有:[Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]

4.4.6 PCI 隨插即用裝置(PCI PnP

本選單可讓您變更 PCI/PnP 裝置的進階設定,其包含了供 PCI/PnP 裝置所 使用的 IRQ 位址與 DMA 通道資源與記憶體區塊大小設定。

注意!在您進行本進階選單的設定時,不正確的數值將導致系統 損毀。

BIOS SETUP UTILITY

Advanced

Advanced PCI/PnP Settings

WARNING: Setting wrong values in below sections may cause system to malfunction.

Plug And Play O/S

[NO]

NO: Lets the BIOS configure all the devices in the system.

YES: Lets the operating system configure Plug and Play (PnP) devices not required for boot if your system has a Plug and Play operating system.

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.

Plug And Play O/S [No]

當設為 [No]BIOS 程式會自行調整所有裝置的相關設定。若您安裝了支援 隨插即用功能的作業系統,請設為 [Yes]。設定值有:[No] [Yes]

華碩 P5KC 主機板使用手冊 4-25
