19. SPECIFICATIONS

MEDIA SECTION

USB Host

Memory Card

Support Type of Memory Card

RADIO SECTION

FM

Frequency Range

Intermediate Frequency

Usable Sensitivity

Stereo Separation

S/N Ratio

AM/MW

Frequency Range

Intermediate Frequency

Usable Sensitivity

S/N Ratio

BLUE TOOTH

Power Consumption

Output Power

Frequency Band

Range

Standard

Host 1.1 compatibles 2.0

SD and MMC

87.5-108Mhz

87.5-107.9Mhz

10.7 MHz

Better than 15dB at S/N 30 dB 25 dB at 1KHz

50 dB

522-1620KHz

530-1720 KHz 450KHz

Better than 45dB 40 dB

200mA Max.

0 dBm (Class II)

2.4GHz ~ 2.4835GHz ISM Band 3 meters (free space)

Bluetooth 1.2 specification

GENERAL

Power Supply

DC 11 -14V

Polarity

Negative Ground

Speaker impedance

4 ohms

Power Output

4 x 80W

REMARK :

Specifications subject to change without notice.
