Step 27
Install drain by placing rubber gasket around opening in bottom of basin. Insert drain through opening. Place second gasket under bottom side of the basin and over the drain. Secure using large plastic nut provided with drain. Hand tighten.
Step 28
Place faucet through the hole in the basin with one washer above and one washer below the basin. Secure with plastic nut provided.
Step 29
Attach smaller end of water supply hose to the threaded end of the faucet. The male end of a standard garden hose will fit the free end of the supply hose and provide water to the faucet.
Step 30
Attach the drain hose to threaded end of the drain.
Step 31
Place ice bucket into the opening next to the sink in the upper kitchen frame. The removable lid can serve as a cutting board. Finger hole should be oriented to the back of the grill.
Step 32
Place briquet grate into lower grill housing. The grate should rest on the ledge just above the burner level.
Step 33
Place ceramic briquets, flat side down, onto briquet grate. Space out the briquets evenly on the briquet grate.
Step 34
Place cast iron cooking grill on support ribs in lower grill housing.
Cutting Board
Strainer
Water Supply Hose
Water Supply Garden Hose
(Not supplied)
27
