Make an internal call handset to handset only | BT 6300 instruction

6488 BT Freestyle 6300 UG [4] 18/10/04 11:02 am Page 51

BT Freestyle 6300 – Edition 4.0 – 15.10.04 – 6488

Additional handsets & bases	51

Make an internal call handset to handset only

If you have two or more handsets registered to your base, you can make internal calls between handsets.

Two handsets can be holding an internal call while a third is on an external call.

1.Press . The display shows Handset: then enter the handset number you want to call (e.g. 1-5).

2.The receiving handset displays the number of the handset calling, eg. Handset: 1. Press to answer the internal call or remove the handset from the base.

3.Press on either handset to end the call.

Make an internal call from the base to another handset

1.Press on the base. All registered handsets will ring and display Call. The first handset to press will take the call.

2.Press on either handset or base to end the call.

Transferring calls

You can transfer an external call to another handset registered to the base.

Image 51

BT 6300 manual Make an internal call handset to handset only
