Page 52

FITTING OPTIONAL RACKMOUNT EARS

The part numbers for the kits are:

RW5744 RACK MOUNTING KIT - EPM6

RW5745 RACK MOUNTING KIT - EFX8/EPM8

RW5746 RACK MOUNTING KIT- EFX12/EPM12 (included with consoles for models shipped 2010 onwards)

Note: a rack extender is included in the EFX8/EPM8 rack mounting kit to make the console fit into a 19” frame, see the fitting instructions below.

50	Soundcraft EFX/EPM User Guide Issue 1210
