Specifications (Cont.)

	Horizontal sync/composite sync signal (H/Cs)
	H	: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)
	Cs	: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)
	Vertical sync signal (V)
	V	: 1V(p-p) to 5V(p-p), high impedance (positive/negative polarity)
	* Some connected devices may not correspond to composite sync (Cs) or G on sync signal.
• AUDIO	1-line, stereo mini-jack × 1
(For COMPUTER IN-2) 0.5V(rms), high impedance
[COMPUTER OUT (COMPUTER OUTPUT)]
• COMPUTER OUT	1-line, D-sub 3-row 15-pin × 1
	Analog RGB signal
	R	: 0.7V(p-p), 75Ω
	B	: 0.7V(p-p), 75Ω
	G	: 0.7V(p-p), 75Ω
	G on sync : 1V(p-p), 75Ω (negative sync)
	Horizontal sync/composite sync signal (H/Cs)
	H	: TTL level (Polarity : Same for input)
	Cs	: TTL level (Polarity : Same for input)
	Vertical sync signal (V)
	V	: TTL level (Polarity : Same for input)
• AUDIO OUT	1-line, stereo mini-jack × 1
	0V(rms) to 0.5V(rms) (variable output)
[CONTROL]
• RS-232C	: 1-line, D-sub 9-pin × 1
	* RS-232C-interface specified control terminal for controlling this projector with a personal
	computer.
• REMOTE	: 1-line, mini-jack × 1
	* Remote terminal for connecting an infrared remote sensor extension unit, etc.
[Other]
• Audio power output	1 W + 1 W
(effective)
• Built-in speaker	6 cm × 3 cm (2-3/8˝ × 1-1/8˝) oval type × 2, impedance 8Ω
General
• Power requirements		AC120 V, 60 Hz
• Power consumption		8 A (7 W during stand-by)
• Allowable operation temperature		+ 5°C to + 35°C (41°F to 95°F)
• Allowable relative humidity		20% to 80% (no condensation)
• Allowable storage temperature		– 10°C to + 60°C (14°F to 140°F)
• Maximum outside dimensions		Approx. (W)425 mm × (H)246 mm × (D)421 mm (16-3/4˝ × 9-3/8˝ × 16-5/8˝)
		(excluding protruding parts)
• Weight		Approx. 33.88 lbs.(15.4kg)
• Accessories		(Refer to page 5.)

*Design and specifications are subject to change without notice.

*D-ILA devices are manufactured with a very high-precision technology, allowing 99.99% of the pixels to be effective. Only 0.01% or less of the pixels are missing or always on.

*For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed, and may be more or less different from actual products.

*TRADEMARKS

IBM ,IBM PC, and VGA are registered trademarks of International Business Machines Corporation. Macintosh is registered trademarks of Apple Computer, Inc.

VESA is a trademark of the non-profit organization Video Electronios Standard Association.

All other product names mentioned herein are used for identification purposes only, and may be the trademarks or registered

trademarks of their respective companies.
