McIntosh C500 owner manual Setup, con’t, Trim Level Adjustment

Setup, con’t

Figure 29

3.Rotate the SELECT 1 Control until the desired Input Title to be changed appears in the Display, e.g. “D PORT CDR 5”. Refer to figure 29.

4.Rotate the SELECT 2 Control until the number 2 ap- pears in the Display, e.g. “D PORT CDR 6”. Refer to figure 30.

Figure 30

Note: Connect a 1/8 inch Stereo Mini “Y” adapter to Data Port number 6 on the C500 Controller. From each leg of the “Y” adapter connect a Cable to the Data In jacks on each CD Player.

5.If there are any other Data Port re-assignments to be made, repeat steps 3 and 4.

Note: DATA PORTS may also be switched off by selecting “- -” using the SELECT 2 Control Refer to figure 31.

Figure 31

6.If no other adjustments are to be made at this time, press the SETUP Push-button to exit the Setup Preamp Mode or proceed to the next desired Setup Preamp Mode for adjustment.

Trim Level Adjustment

Various source components can have slightly different vol- ume levels. This could result in the constant need to readjust the C500 Volume Control when switching between different Input Sources. The Level Input Trim Feature on the C500 Controller allows the adjustment of levels for each of the Source Inputs, so that they have the same relative volume. The Tuner and CD Inputs are used in the following ex- ample.

Notes: The possible range of adjustment in volume level is ±6dB. The Tape/Record Output Levels are unaffected by any changes in the Level Trim Settings. Any LEVEL Trim adjustments made are retained in permanent memory and can be changed only by performing a new Level Trim Procedure. The Tuner Input Volume Level can serve as a reference or choose another Input

Source that is frequently listened to as the reference. The reference Input Source should be set to a Level of 00.

1.Rotate the SELECT 2 Control to select the Tuner Input and adjust the VOLUME Control to the desired listen- ing level. Refer to figure 32 .

Figure 32

Note: If the C500 Controller is in the SETUP Mode, exit before proceeding.

2.Press the SETUP Push-button twice to access the Setup Preamp Mode, unless the C500C is already in the Setup Preamp Mode.

3.Rotate the MENU Control until the words “TRIM 0.0 TUN” appears. Refer to figure 33.

Figure 33

Note: The Level Input Trim can also be set via the Remote Control.

4.If necessary, rotate the SELECT 2 Control until the word TUN appears on the right side of the Front Panel Alphanumeric Display, “TRIM 0.0 TUN”.

5.If necessary, rotate the SELECT 1 Control until two zeros appears in the center of the Front Panel Alphanu- meric Display, “TRIM 0.0 TUN”.

6.Rotate the SELECT 2 Control until the word CD ap- pears on the right side of the Front Panel Alphanumeric Display, “TRIM 0.0 CD”. Refer to figure 34.

Figure 34

7.Rotate the SELECT 1 Control until the Volume Level of the CD Input is the same as the Tuner Volume Level. Figure 35 indicates a 3.0dB decrease in the CD Level.

Figure 35

8.Rotate the SELECT 2 Control until the next desired In- put Source Name is displayed.

9.Repeat steps 6, 7 and 8 until all the Inputs with sources connected to the C500 have the same relative volume levels when switching between them.
