Multiquip WM-120PM operation manual WM-120P/S - HONDA ENGINE ASSY

WM-120P/S — HONDA ENGINE ASSY.

HONDA ENGINE ASSY.
NO	PART NO	PART NAME	QTY.	REMARKS
1	EM203039	11HP HONDA ENGINE	1
2	EM940734	KILL SWITCH	1
3	EM203298	ENGINE KILL GROUND WIRE	1
4	EM203035	ENGINE KILL WIRE	1
5	9154	HHCS 3/8-16 X 1.3/4”	4
6	10136	FLAT WASHER 3/8”	8
7	EM100235	ENGINE SHIM .030	AR
	EM100236	ENGINE SHIM .018	AR
	EM100237	ENGINE SHIM .010	AR
8	EM203007	ENGINE PAD .187	AR
	EM203016	ENGINE PAD .135	AR
	EM203017	ENGINE PAD .060	AR
9	10133	LOCK NUT 3/8-16	4
10	EM204550	MOTOR MOUNT	2
11	EM203038	ADAPTER KIT ............................................................. 1 .......... INCLUDES ITEMS W/
12	11090	STUD, 3/8 SHC	4	*
13*	EM927066	SQ KEY	1
14	EM961045	SHSS 5/16-18 X 1/2”NYLOC	1
15#	EM925013	LEVER PIN	3
16#	EM925018	SHORT LINK PIN	3
17#	EM925016	LONG LINK PIN	3
18#	EM959012	LEVER	6
19#	EM934054	ROLLER	3
20#	5117	COTTER PIN	9
21#	EM934053	CONNECTING LINK	6
22	9503	SLOTTED HHCS 1/4-20 X 1/2”	1
23#	EM934040	ADJUSTING LOCK	1
24#	EM934039	CLUTCH HOUSING	1
25#	EM918009	SPRING	3
26#	EM934041	SPLINED CENTER W/FACING	1
27#	EM934042	PRESSURE PLATE ASM	1
28#	EM934043	RELEASE SLEEVE	1
29#	EM934045	ADJUSTING RING	1
30#	EM963289	BOLT	2
31#	EM969009	LOCK NUT	2
32#	EM934044	RELEASE BEARING ASM	1
33	1475	WIRE SPLICE	1
34	EM203149	EXHAUST DEFLECTOR	1
35	EM203040	SLEEVE	1
36*	EM801570	PILOT BUSHING	1
37	EM934022	CLUTCH ASM ............................................................. 1 .......... INCLUDES ITEMS/W#
38*	13377	OIL SEAL	4
39*	13379	COPPER WASHER	4

WHITEMAN WM-120P/S — PARTS & OPERATION MANUAL — REV. #6 (07/20/05) — PAGE 43
