THE MENU SYSTEM
THE DISH POINTING MENU SCREEN
Follow these steps to obtain your dish pointing coordinates:
1.Turn on your television and satellite receiver.
2.Tune your television to the satellite receiver’s output channel.
3.Press MENU•SELECT on the remote or front panel to bring up the Main menu.
4.Use the arrows to highlight the “Dish Pointing” option, and then press MENU•SELECT to access the dish pointing screen.
NOTE: The menu screen that you see may be slightly different from the one pictured here.
5.Use the arrows on the remote or the front panel to highlight “Zip Code” and then press MENU•SELECT.
6.Enter the zip code for the dish installation location.
7.Record the elevation and azimuth numbers below.
Elevation ___________ | Azimuth __________ |
Elevation is the up/ down angle that the dish is pointed.
Azimuth is side to side direction that the dish is pointed.
You only need to use one of the available methods to find your dish pointing coordinates. If you know the zip code for the locality where the dish is being installed, use that.
