Snapper GM2513H, BC25BE Safety Rules and Information, Slope Operation, Children, Service, Do Not

Page 4

SLOPE OPERATION

WARNING

Never operate on slopes greater than 17.6 percent (10°) which is a rise of 3-1/2 feet (106 cm) vertically in 20 feet (607 cm) horizontally.

Select slow ground speed before driving onto slope. In addition to front and rear weights, use extra caution when operating on slopes with rear-mounted grass catcher.

Mow across the slope, never up and down, use cau- tion when changing directions and DO NOT START OR STOP ON SLOPE.

Slopes are a major factor related to slip and fall acci- dents, which can result in severe injury. All slopes require extra caution. If you feel uneasy on a slope, do not mow it.

Do

Mow across the face of slopes; never up and down. Exercise extreme caution when changing direction on slopes.

Remove obstacles such as rocks, tree limbs, etc.

Watch for holes, ruts, or bumps. Tall grass can hide obstacles.

Do Not

Do not mow near drop-offs, ditches, or embank- ments. The operator could lose footing or balance.

Do not mow excessively steep slopes.

Do not mow on wet grass. Reduced footing could cause slipping.

CHILDREN

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the unit and the mowing activity. Never assume that chil- dren will remain where you last saw them.

Keep children out of the mowing area and under the watchful care of another responsible adult.

Be alert and turn mower off if children enter the area.

Before and while moving backwards, look behind and down for small children.

Never allow children to operate the mower.

Use extra care when approaching blind corners, shrubs, trees, or other objects that may obscure vision.

Safety Rules and Information

SERVICE

Use extra care when handling gasoline and other fuels. They are flammable and vapors are explosive.

a)Use only an approved container.

b)Never remove fuel cap or add fuel with the engine running. Allow engine to cool before refueling. Do not smoke.

c)Never refuel the machine indoors.

d)Never store the machine or fuel container inside where there is an open flame, such as a water heater.

Never run an engine inside a closed area.

Never make adjustments or repairs with the engine (motor) running. Disconnect the spark plug wire, and keep the wire away from the plug to prevent acciden- tal starting.

Keep all nuts and bolts, especially blade attachment bolts, tight and keep equipment in good condition.

Never tamper with safety devices. Check their prop- er operation regularly.

Keep mower free of grass, leaves, or other debris build-up. Clean up oil or fuel spillage. Allow mower to cool before storing.

Stop and inspect the equipment if you strike an object. Repair, if necessary, before restarting.

Never attempt to make wheel height adjustments while the engine (motor) is running.

Always disconnect electric mowers (live operated) before cleaning, repairing, or adjusting.

Grass catcher components are subject to wear, dam- age, and deterioration, which could expose moving parts or allow objects to be thrown. Frequently check components and replace with manufacturer’s recom- mended parts, when necessary.

Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves, and use extra caution when servicing them.

Do not change the engine governor setting or over- speed the engine.

* Asterisked items do not apply to electric mowers.

EMISSIONS

Engine exhaust from this product contains chemicals known, in certain quantities, to cause cancer, birth defects, or other reproductive harm.

Look for the relevant Emissions Durability Period and Air Index information on the engine emissions label.

3

Image 4
Contents OPERATOR’S Manual Table of Contents Safe Operation Practices for WALK-BEHIND Mowers General OperationSafety Rules and Information ServiceSlope Operation ChildrenSafety Rules & Information Safety DecalsDecal Warning Decal Engine Throttle ControlDecal Danger Dismemberment Decal Danger Flying ObjectsFeatures & Controls Control FunctionsStarting the Engine Engaging the TransmissionBefore Starting Engine To Start EngineTo Propel Unit Forward Operating the MowerTo Propel Unit In Reverse ENGAGING/DISENGAGING the Cutting Blade To Disengage Cutting BladeTo Adjust Cutting Height StorageRegular Maintenance Service Interval Every 25 HoursLubrication Lubricate Rear Axle ShaftsRegular Maintenance Battery ServiceCleaning the Battery and Cables 9HP Models Cleaning the Battery and Cables All Models Except 9HPServicing the Mower Blades Removing the BladeTroubleshooting Adjustment, & Service TroubleshootingTroubleshooting, Adjustment & Service TroubleshootingTroubleshooting, Adjustment, & Service Travel Control AdjustmentSerial Number Serial Number 012003001-UpBlade Clutch Adjustment Shut off engine before attempting this adjustment procedureBlade Brake Adjustment Mower Belt AdjustmentFor S/N 0 Traction Drive Belt AdjustmentFor S/N 071601076 up Troubleshooting, Adjustment & Service Mower Belt ReplacementSpecifications Parts & AccessoriesReplacement Parts Maintenance ItemsPage Products, Inc Macon Street/PO Box McDonough, GA

GM2513BS, GM2515KAW, BC25BE, BC25H, GM2513H specifications

The Snapper FB15250KW, GM2513H, BC25H, BC25BE, and GM2515KAW are a series of robust outdoor power equipment designed to tackle a variety of landscaping tasks. Each model comes with unique features and characteristics that cater to different user needs, ensuring efficient performance and reliability.

The Snapper FB15250KW is a versatile 21-inch push lawn mower equipped with a powerful 150cc engine. It features a 3-in-1 cutting system, allowing users to mulch, bag, or side discharge grass clippings. Its lightweight design and ergonomic handle make it easy to maneuver, while the adjustable cutting height provides flexibility for varying grass conditions. The easy-start engine technology ensures quick and reliable starting in any weather, making it a favorite for homeowners.

The GM2513H model is a gas-powered walk-behind mower that focuses on durability and performance. Its 25-inch cutting deck allows for larger mowing areas, perfect for medium to large lawns. This mower is equipped with self-propelling capabilities, which significantly reduces user effort during operation. The mower’s high rear wheels provide stability and traction on rough terrain, enhancing overall mowing efficiency.

For those looking for a string trimmer, the BC25H and BC25BE models offer exceptional performance. The BC25H features a powerful two-cycle engine and a straight shaft design, making it ideal for trimming hard-to-reach areas. Its lightweight build ensures maximum comfort during extended use. The BC25BE, similarly equipped with a robust engine, adds versatility by incorporating a detachable design for easy storage and transportation.

Lastly, the GM2515KAW is a high-performance riding mower tailored for extensive lawns. It boasts a powerful engine and a wide cutting deck, which cuts down mowing time significantly. The comfortable seat and adjustable steering provide an excellent user experience, allowing operators to navigate their lawns with ease. Additionally, the mower is designed with advanced safety features, ensuring user confidence during operation.

In summary, the Snapper FB15250KW, GM2513H, BC25H, BC25BE, and GM2515KAW cater to diverse landscaping needs, providing users with efficiency, ease of use, and reliability. These models embody Snapper's commitment to quality, making them ideal choices for both residential and professional applications in lawn care.
