CODE OPERATED SWITCH II

After you have hit a key, the screen will change to:

Serial Port Test

SERIAL PORT TEST (EXPANSION BOARD IS NOT INSTALLED)

PORT#

DATA

DTR/CTS/RI

RTS/DCD

MASTER

*

FAILED

FAILED

PORT 0

FAILED

FAILED

FAILED

PORT 1

FAILED

FAILED

FAILED

PORT 2

FAILED

FAILED

FAILED

PORT 3

FAILED

FAILED

FAILED

SERIAL PORT TEST FAILED

The Serial Port Test is a loopback test that checks whether data is being correctly transmitted and received on any port. The test also checks, using DTR/CTS/RI or RTS/DCD, whether the box can loop back control leads correctly. To use this test, you will need to jumper Pins 2 and 3. To test DTR/CTS/RI and RTS/DCD, you’ll need to jumper Pins 20, 5, and 22 together, and jumper Pins 4 and 8 together.

Interrupt Test

INTERRUPT TEST IN PROGRESS

A

INTERRUPT TEST PASSED

The Interrupt Test checks the interrupt circuitry of the unit. During this test, the letter “A” will appear on screen. A message will indicate whether the test was successful.

All Tests

If you request All Tests, the COS-II will run all the listed tests in sequence.

20

Image 20
