Page 23

IMPORTANT

When you connect a FDD unit (USB), the floppy disk access indicator in the status indicator LCD does not appears even a floppy disk is accessed. You should check the access to the floppy disk with the access lamp on the FDD unit (USB). Make sure that the access lamp does not light up when you eject a floppy disk.

9 PC Card Access Indicator (



1





2

)













This indicator appears when a PC card is accessed. 1 indicates the PC card slot on the PC and 2 indicates the PC card slot of the built-in PC card unit installed on the mobile multi-bay. See POINT below.

!Num Lock (Numerical Lock) Indicator ( 1 )

This indicator appears when the keyboard is set to numeric keypad mode.You can set and reset the numeric keypad mode by pressing the [Num Lk] key.

!Caps Lock Indicator ( A )

Lights when the caps lock function is activated.

To switch the caps lock function on and off, press the [Caps Lock] key while holding the [Shift] key.

#Scroll Lock Indicator ( )

Lights when the screen is set not to be scrolled (scroll lock).

To switch the scroll lock function on and off, press the [Scr Lk] key while holding the [Fn] key. The function of the PC depends on the application when this indicator appears.

Critical Points

￿While the hard disk access indicator or the floppy disk access indicator lights, setting the MAIN switch off or pressing the SUS/RES switch may damage the data on the hard disk or the floppy disk (or the super disk).

￿Setting the MAIN switch off causes all the indicators on the status indicator LCD to go off except when the battery is being charged.

￿For some operation systems, you may have to read “Slot 1” of the PC card access indicator as “Slot 0” and “Slot 2” as “Slot 1”.

￿When you use Windows 98 / Windows Me or Windows 95 and the CD auto insert function is enabled, the system periodically detects whether the slot has a CD. As a result, the CD access indicator on the status indicator LCD goes on periodically. To disable the CD auto insert function, take the following procedures:

SECTION 1

13
