5 BX600 Graphical User Interface

The Fujitsu Siemens BX600 Digital KVM Switch allows you to access the blades in a BX600 Blade Server using a Graphical User Interface (GUI).

To access the Fujitsu Siemens Management Blade (MMB) GUI:

Point your browser to the IP address of the MMB to access the BX600 Digital KVM Switch.

When the Fujitsu Siemens Management Blade GUI is called up, the first screen that appears has a list of folders in the left hand column that consist of the following:

System Property

Management Blade

Lan Switch Blade

DKVM Blade

Server Blade

5.1DKVM Blade Folder Contents

The scope of this chapter will discuss the DKVM Blade folder, its contents and how to perform the various tasks.

To access the DKVM Blade folder pages:

Click the plus sign (+) next to the DCVM folder icon in the left column of the GUI screen.

The DKVM Blade folder contains the following pages:

Blade Info

Network Configuration

Console Redirection

Virtual Media

Firmware Update

5.2Blade Info

Blade Info is a page in the folder that displays the information about the BX600 Digital KVM switch that is installed in the BX600 blade server.

To access the Blade Info page:

Select Blade Info from inside the DKVM Blade folder in the left column.

When this page is selected, the BX600 reads the blade information from the BX600 Digital KVM switch. This page shows the following items:

DKVM blade Manufacture

DKVM blade Manufacture Date

DKVM blade Serial Number

DKVM blade Product Name

DKVM blade Model Name

590-673-501A
