Color monitor 4612 FA

Connecting cables to the computer

Information on the computer connections and interfaces is contained in the operating manual for your computer.

i	If your computer has two monitor ports ("onboard" screen controller and separate
	graphics card), the monitor port for the separate graphics card is usually active.

ÊConnect the data cable to the (active) monitor port on the computer and secure the plug-in connection by tightening the safety screws.

ÊConnect the male receptacle of the power cable supplied to the monitor socket of the computer and ensure a secure connection.

ÊPlug the power connector of the computer into a properly grounded power outlet.

When you start working with your monitor for the first time you should install the

i appropriate graphics drivers for your application software. Details of how to do this are provided in the documentation on your screen controller/the associated driver software.

Operation of the monitor

The monitor offers the following possibilities that enable it to be optimally adjusted for the respective user and the respective situation.

Adjusting height, rake and rotation

The monitor height can be adjusted within a range of approx. 2 in/70 mm.

ÊGrasp the monitor with both hands on the right and left edge of the housing and move it upward or downward.

The rake of the monitor can be adjusted by –5° (forward) and +30° (back) from its vertical position.

ÊGrasp the monitor with both hands on the right and left edge of the housing and adjust it to the desired rake.

The monitor can be rotated by ± 90° from its center position.

ÊGrasp the monitor with both hands on the right and left edge of the housing and rotate it into the desired position.

Adjusting portrait format

The monitor can be turned from the "wide format" (landscape mode) into the "high format" position (portrait mode).

ÊGrasp the monitor with both hands on the right and left edge of the housing, move it into the highest position and turn it clockwise until it is in the portrait position.

ÊPress the RESET button (with the OSD menu switched off) to switch the OSD (On Screen Display) menu from the landscape mode into the portrait mode (also see the section " Monitor settings using the OSD menu").
