IOGear GCS1758 user manual OSD Navigation

Page 31

OSD Operation

Note:

1.The diagram depicts the Administrator’s Main Screen. The User Main Screen does not show the F4 ADM function.

2.OSD always starts in List view, with the highlight bar at the same position it was in the last time it was closed.

3.Only the ports that have been set accessible by the Administrator for the currently logged in User are visible (see Set Accessible Ports, p. 35, for details).

OSD Navigation:

To dismiss the menu, and deactivate OSD, Click the X at the upper right corner of the OSD Window; or press [Esc].

To Logout, Click F8 at the top of the Main Screen, or press [F8].

To move up or down through the list one line at a

time, Click the Up and Down Triangle symbols (

) or use the Up and Down Arrow Keys. If there are more list entries than what can appear on the Main Screen, the screen will scroll.

To move up or down through the list one screen at

a time, Click the Up and Down Arrow symbols (

), or use the [Pg Up] and [Pg Dn] keys. If there are more list entries than what can appear on the Main Screen, the screen will scroll.

To activate a port, Double Click it, or move the Highlight Bar to it then press [Enter].

After executing any action, you automatically go back to the menu one level above.

28
