Page 33

OSD Operation

3.Press [Esc] to return to the previous menu level.

F1 GOTO:

GOTO allows you to switch directly to a port either by keying in the port’s Name, or its Port ID.

-To use the Name method, key in 1; key in the port’s Name; then press [Enter].

-To use the Port ID method, key in 2; key in the Port ID; then press [Enter].

Note: You can key in a partial Name or Port ID. In that case, the screen will show all the computers that the User has View rights to (see Set Accessible Ports, p. 35), that match the Name or Port ID pattern, regardless of the current List settings.To return to the OSD Main Menu without making a choice, press [Esc].

F2 LIST:

The LIST function lets you broaden or narrow the scope of which ports the OSD displays (lists) on the Main Screen. Many of the OSD functions only operate on the computers that have been selected for listing on the Main Screen with this function. The choices and their meanings are given in the table below:

30
