Sony FWD-S47H1 manual Soft Version Main CPU/LAN, Code -k

(d) Soft Version (Main CPU/LAN)

Syntax	Header	Category		Function	Data1		Data2	Check Sum
Enquiry	0x83	0x30		Code Table	0xFF		0xFF	0xB4
				(4-k)
Answer	Header	Answer	Return to Data Size			Return Data1		Return Data2		Check Sum
Enquiry	0x70	0x00	Code Table			Upper 8bit Data		Lower 8bit Data		0xXX	Completed
			(4-k)
Return Data1-Data2: 0x0000-0xFFFF (BCD Format)
ex) In Version0.100, it is set to 01 and 00.
Code Table (4-k)
Function		Return Data
0x03 Main CPU		0x0000-0xFFFF
0x0F LAN		0x0000-0xFFFF
(e) 8bits Register
Syntax	Header	Category		Function			Data1	Data2	Check Sum
Enquiry	0x83	0x30		Code Table (4-b)			0xFF	0xFF	0xXX
Answer	Header	Answer	Return to Data Size				Return Data1	Check Sum
Enquiry	0x70	0x00	0x02				Code Table (4-b)	0xXX		Completed

Code Table (4-b)*

Function		Return Data	Unit
0x07	Digital 3.3 V	0x00-0xFF
0x08	Analog 24 V	0x00-0xFF
0x09	Digital 5 V	0x00-0xFF
0x0A	Temp1	0x00-0xFF
0x0B	Temp2	0x00-0xFF
0x0D	Inverter Alarm	0: Normal, 1: Abnormal
0x11	Shutdown Log	0x00-0xFF
0x12	Digital 3.3 V (Failure)	0x00-0xFF
0x13	Digital 5 V (Failure)	0x00-0xFF
0x14	Analog 12 V (Failure)	0x00-0xFF
0x16	Analog 12 V	0x00-0xFF

*

.For function 0x07, 0x08, 0x09, 0x11, 0x12, 0x13, 0x14 and 0x16 in the left table

When the display value is 3.0 V,“0x1E”(30) is returned.

.For function 0x0A, 0x0B and 0x0D in the left table When the display value is 50 dC,“0x32”(50) is returned.

When the display value is _20 dC, “0xEC”is re- turned.

FWD-S42H1 21
