DAYLIGHT VIEW

You can keep the projected image bright and vivid even in well-lit rooms where the ambient light sources cannot be controlled, such as when a door opens or when window coverings fail to block out sunlight.

Change setting Change setting

AUTO





ON





OFF









AUTO



Automatic adjustment



ON



Active



OFF



Deactive



Remarks

zzDo not cover the Ambient Luminance Sensor (ALS) of the projector. The AUTO mode may not operate normally.

zzAUTO is not available when INSTALLATION in PROJECTOR SETUP menu is set to REAR/DESK or REAR/CEILING.

STILL MODE

You can reduce the vertical flicker when projecting a still image.

(Available with signals of S-VIDEO/VIDEOonly)

Change setting Change setting

OFF

Deactive

ON

Active

Note

zzYou must set to OFF when projecting a moving image.

NOISE REDUCTION

You can switch the automatic noise reduction system on/off.

(Available with signals of S-VIDEO/VIDEOonly)

Change setting Change setting

OFF

No noise reduction

ON

Automatic noise reduction

Note

zzNOISE REDUCTION is set active when the selected input signal has less noise. Applying noise reduction may affect the image quality, if so, set to OFF.

PICTURE menu

TV-SYSTEM

When the video signal is changed, the setting switches automatically. You can switch the setting manually to match the video data.

(Available with signals of S-VIDEO/VIDEOonly)

Change setting Change setting

AUTO



NTSC



NTSC4.43

SECAM PAL-N PAL-M PAL

Note

zzAUTO mode is selected by default.

zzWhen the projector is not working properly in AUTO mode, change the setting according to each TV system type.

Remarks

zzAUTO setting will automatically select the compatible signal from NTSC/NTSC 4.43/PAL/PAL60/PAL-M/

PAL-N/SECAM.

RGB/YPBPR

AUTO mode is selected by default. If the image is not projected normally in the AUTO mode, select RGB or YPBPR according to the input signal.

The function becomes effective only when certain signals below are input.

(VGA60, 480i, 576i, 480p, 576p, 1 080/60i, 1 080/50i, 720/60p, 720/50p)

Select the signals to be input to the COMPUTER1 and COMPUTER2 IN terminal.

Change setting Change setting

AUTO

Automatic adjustment

RGB

For RGB signals

YPBPR

For YPBPR signals

Settings

ENGLISH - 33

Image 33
