PICTURE menu

COLOR TEMPERATURE

You can adjust the white balance of the projected image.

LOW

More bluish

DEFAULT

Balanced white

HIGH

More reddish

DAYLIGHT VIEW

You can keep the projected image bright and vivid even in well-lit rooms where the ambient light sources cannot be controlled, such as when a door opens or when window coverings fail to block out sunlight.

AUTO: Automatic adjustment

ON: Active

OFF: Deactive

NOTE:

Do not cover the Ambient Luminance Sensor (ALS) of the projector. See “Ambient Luminance Sensor (ALS)” on page 14.

AUTO is not available when INSTALLATION setting in OPTION menu is set to REAR/DESK or

REAR/CEILING.

DIGITAL CINEMA REALITY

You can improve the vertical resolution of a 2-2 or 2-3 pulldown movie. Press I H to select the required setting. (Not available with NETWORK signals)

OFF

Deactive

ON

Active

NOTE:

• Available with 480i, 576i, 1 080/60i and 1 080/50i only.

TV-SYSTEM

When the video signal is changed, the setting switches automatically. You can switch the setting manually to match the video data. Press I H to cycle through the options. (Available with S-VIDEO/VIDEOonly)





AUTO





FG



FG









NTSC



SECAM

FG



FG









NTSC 4.43



PAL-N









FG



FG









PAL

IH

PAL-M

NOTE:

AUTO setting will select from NTSC/NTSC 4.43/PAL/ PAL60/PAL-M/PAL-N/SECAM.

RGB/YPBPR

The projector will detect the signal from the COMPUTER terminals if the signal is RGB or YPBPR. You can turn off the automatic detecting system and switch between RGB and YPBPR manually.

AUTO: Automatic detecting system

RGB: Project as RGB signal

YPBPR: Project as YPBPR signal

NOTE:

Available with VGA60, 480i, 576i, 480p, 576p,

1080/60i, 1 080/50i, 720/60p, 720/50p, 1 080/60p,

1080/50p only.

When the input signal is not selected correctly with AUTO setting, select RGB or YPBPR manually.

Settings

NOISE REDUCTION

You can switch the automatic noise reduction system on/ off. Press I H to select the required setting.

ON: Automatic noise reduction

OFF: No noise reduction

NOTE:

• Applying noise reduction may affect image quality.

ENGLISH - 36
