Appendix A - Troubleshooting

Cash Drawer Cable Wiring

The figure below displays the pin assignments for the printer's retail cash drawer interface. Re- fer to the cash draw manufacturer's documenta- tion for proper drawer wiring.

RJ-11

Pin No.

1

2

3

4

5

6

PRINTER

SGND

/SDRV1

/Sense

+24V*

/SDRV2

LGND

Male RJ-11

*+24 volts D.C. at no greater than 1.5 amps.

980293-001 Rev. A

17
