5. If the release lever is lowered, press it again and raise the release lever.

Note:

If you insert paper that is too small (shorter than 85 mm) by mistake, you may not be able to remove it from the top of the auto sheet feeder, so use paper of the right size. If you cannot remove paper that you inserted, see "A paper jam occurred" on page 3-9.

3.1.1.2 Printing method

1.Check the following 3 points before printing.

•The printer is turned on

•The release lever is up

•Paper is set in the auto sheet feeder

2.When a print command is sent from an application, the printer prints the data.

Note:

As a preliminary operation before printing, the printer feeds the paper and retracts it again. Do not pull the paper during this operation.

During printing, do not press the release lever. If you press the release lever to release it during printing, printing stops and all the print data is lost.

If you open the printer cover during printing, printing is paused. When the printer cover is closed, printing restarts.

3.1.2With the roll paper specification

3.1.2.1 How to install and replace paper

CAUTION:

Use Epson roll paper. Using the wrong paper may result in inferior prints and paper jams.

Note:

For part names, see "Part names" on page 2-1.Also see the label on the outside of the roll paper holder for instructions on setting the roll paper.

1.Be sure that the printer power is turned on. If the power is turned off, turn it on.

2.Press the release lever to open the paper entrance.

3.If the roll paper edge guide is attached to the roll paper holder, squeeze the locking clip of the roll paper edge guide and remove the edge guide. Be sure not to lose the removed roll paper edge guide.

3-2Using the Printer

Rev. C
